WANDA 450-FLAT ESP CABLE
DESCRIPTION: BARE SOLID COPPER CONDUCTOR, EPDM INSULATION, LEAD SHEATH, FIBER TAPE COMPLETELY COVERED THE SHEATH, GALVANIZED STEEL (SS OR MONEL)ARMOR STANDARD: IEEE1018, API RP11S5, API RP 11S6
-
WANDA 450-ROUND ESP CABLE
DESCRIPTION: SOL BARE COPPER, EPDM INSULATION, LEAD SHEATH, FIBER TAPE COMPLETELY COVERED THE SHEATH, GALVANIZED STEEL (SS OR MONEL)ARMOR STANDARD: IEEE1018, API RP11S5, API RP 11S6
-
WANDA 400-ROUND ESP CABLE
DESCRIPTION: SOL BARE COPPER, EPDM INSULATION, FEP AS SECOND INSULATION TO BETTER CABLE ELECTEICAL JACKET, GALVANIZED STEEL (SS OR MONEL)ARMOR STANDARD: IEEE1018, API RP11S5, API RP 11S6
-
WANDA 450-FLAT+CT ESP CABLE
DESCRIPTION: BARE SOLID COPPER CONDUCTOR, EPDM INSULATION, LEAD SHEATH, FIBER TAPE COMPLETELY COVERED THE SHEATH, SS MATERIAL CAPILLARY TUBE, GALVANIZED STEEL (SS OR MONEL)ARMOR STANDARD: IEEE1018, API RP11S5, API RP 11S6
-
WANDA 450-MLE CABLE
BARE SOLID COPPER CONDUCTOR, EPDM+POLYMIDE FILE INSULATION, LEAD SHEATH, FIBER TAPE, COMPLETELY COVERED THE SHEATH, GALVANIZED STEEL (SS OR MONEL)ARMOR STANDARD: IEEE1018, API RP11S5, API RP 11S6
-
MONOCONDUCTOR 7/32'' VS 5/16''
PROPERITIES: Cable Diameter 7 32 (5 6mm) 5 16(8 0mm); Minimum Sheave Diameter 11 (280mm) 16 (400mm); Cable Stretcch Coefficient 2 2 ft Kft Klbs(2 5m Km 5; ELECTRICAL Maximum Conductor Voltage 1,000VAC
-
MONOCONDUCTOR 7/32'' VS 5/16''(1)
PROPERITIES: Cable Diameter 7 32 (5 6mm) 5 16(8 0mm); Minimum Sheave Diameter 11 (280mm) 16 (400mm); Cable Stretcch Coefficient 1 63 ft Kft Klbs(1 83m Km;
-
3-CONDUCTOR 7/32'' VS 5/16'' VS 15/32''
PROPERITIES: Cable Diameter 7 32 (5 6mm) 5 16(8 0mm) 15 32 (11 8mm); Minimum Sheave Diameter 11 (280mm) 16 (400mm) 23 (590mm); Cable Stretcch Coefficient ft Kft Klbs(m Km 5KN) 2 2(2 5) 1 2(1 35) 0 76(0 85);
-
7-CONDUCTOR 7/32'' VS 1/2'' VS 33/64''
PROPERITIES: Cable Diameter 15 32 (11 8mm) 1 2(12 4mm) 33 64 (13 2mm); Minimum Sheave Diameter: 23 (590mm) 25 (620mm) 26 (660mm); Cable Stretcch Coefficient: ft Kft Klbs(m Km 5KN) 0 756(0 85) 0 578(0 65);
